?ADI模擬控制可變增益放大器(VGA)
發布時間：2022-12-28 16:43:37 瀏覽：556
ADI模擬控制可變增益放大器(VGA)各種各樣音頻視頻和光頻頻段能夠在寬動態范圍之內提供連續性增益控制。ADI模擬控制可變增益放大器允許用戶實時調整信號幅度，從而優化了電源的動態范圍，對于超聲波、語音分析、雷達天線、無線通訊和儀表設備相關技術極為重要，所有的應用一般使用模擬控制VGA。
除模擬控制可變增益值放大器外，ADI離散級增益控制還提供了數字控制可變增益值放大器產品線。根據提供模擬控制VGA和數字控制VGA，ADI為管控動態范圍提供解決方案，能夠輕松管理數字控制和增益值之間的平穩運行。
ADI公司為鋰離子電池、鉛酸電池、鎳基電池等所有可充電電池化學應用制造出深厚的性能卓越脈沖電池充電器。LINEAR脈沖充電器無需微控制器/MOSFET/堵塞二極管，提供開關充電器等諸多優勢，簡單性和線性充電器相似。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.yzgnjsb.cn/brand/19.html
產品型號 | Freq Response (min) | Freq Response (max) | Gain dB (min) | Gain dB (max) | OIP3 (typ) | NF (typ) | Is (typ) | Vs span (min) | Vs span (max) |
| Hz | Hz | dB | dB | dBm | dB | A | V | V |
ADRF6521 | 10M | 3G | -3 | 18 |
| 10.5 | 200m | 4.75 | 5.25 |
ADL5246 | 600M | 3G | -13.5 | 31.5 | 37 | 1.8 | 270m | 3.135 | 5.25 |
AD8338 | 0 | 18M | 0 | 80 |
|
| 3m | 3 | 5 |
AD8367S | 10M | 500M | -2.5 | 42.5 |
|
| 39m | 3 | 5.25 |
MAX19791 | 50M | 4G |
| -3.9 |
|
| 13m | 3.15 | 5.25 |
MAX19793 | 1.5G | 6G |
| -7.6 |
|
| 13m | 3.15 | 5.25 |
MAX19794 | 10M | 500M |
| -3 |
|
| 13m | 3.15 | 5.25 |
MAX2092 | 700M | 2.7G |
| 18.1 | 32.5 | 5.2 | 93m | 4.75 | 5.8 |
HMC6187 | 27G | 31.5G | 6 | 19 | 31 | 4.5 | 230m | -5 | 4 |
MAX2090 | 50M | 1G |
| 25.5 | 38 | 4 | 85m | 4.75 | 5.8 |
MAX2091 | 50M | 500M |
| 23 | 24.5 | 5.4 | 254m | 4.75 | 5.8 |
HMC996 | 5G | 12G | -3.5 | 18.5 | 34 | 2 | 120m | 5 | 5.5 |
HMC997 | 17G | 27G | 5.5 | 20.5 | 30 | 3.5 | 170m | 5 | 5 |
MAX19790 | 250M | 4G |
| -4.4 | 31.9 | 4.4 | 7.3m | 4.75 | 5.25 |
AD8264 | 0 | 235M | 0 | 24 |
|
| 99m | 5 | 10 |
ADL5331 | 1M | 1.2G | -14 | 17 | 47 | 9 | 240m | 4.75 | 5.25 |
LTC6412 |
| 800M | -14 | 17 | 35 | 10 | 110m | 3 | 3.6 |
MAX2067 | 50M | 1G |
| 21.9 | 43 | 4 | 123m | 3.135 | 5.25 |
HMC694-Die | 6G | 17G | 1 | 24 | 30 | 5 | 170m | 5 | 5.5 |
HMC694LP4 | 6G | 17G | 0 | 23 | 30 | 6 | 175m | 5 | 5.5 |
MAX2065 | 50M | 1G |
| 19.4 | 42 | 6.5 | 124m | 3.135 | 5.25 |
AD8336 | 0 | 115M | -14 | 46 |
|
| 25m | 6 | 24 |
AD8334 | 100k | 100M | 4.5 | 43.5 |
|
| 116m | 4.5 | 5.5 |
AD8368 | 10M | 800M | -12 | 22 | 34 | 9.5 | 60m | 4.75 | 5.5 |
AD8337 | 0 | 100M | 0 | 24 |
|
| 15m | 4.5 | 10 |
ADL5330 | 10M | 3G | -32 | 21 | 31.5 | 9 | 215m | 4.75 | 5.25 |
MAX2056 | 800M | 1G |
| 15.5 | 39 | 4.5 | 136m | 4.75 | 5.25 |
MAX2057 | 1.3G | 2.7G |
| 15.5 | 37 | 6 | 180m | 4.75 | 5.25 |
AD8335 | 100k | 70M | -10 | 38 |
|
| 76m | 4.5 | 5.5 |
AD8331 | 100k | 120M | -4.5 | 43 |
| 4.15 | 25m | 4.5 | 5.5 |
AD8351 | 1M | 2.2G | 0 | 26 | 31 | 15.5 | 28m | 3 | 5.5 |
AD8330 | 0 | 150M | 0 | 50 |
|
| 20m | 2.7 | 6 |
AD8332 | 100k | 100M | -4.5 | 43.5 |
| 4.2 | 58m | 4.5 | 5.5 |
AD8367 | 10M | 500M | -2.5 | 42.5 | 36.5 | 6.2 | 26m | 2.7 | 5.5 |
AD604 | 100k | 40M | 0 | 48 |
| 8.4 | 31m | 10 | 10 |
AD605 | 100k | 40M | -14 | 34 |
| 8.4 | 23m | 4.5 | 5.5 |
AD603 | 16k | 90M | -11 | 31 |
| 8.8 | 20m |
| 6.3 |
AD600 | 100k | 10M | 0 | 40 |
|
| 14m | 4.75 | 5.25 |
AD602 | 100k | 10M | -10 | 30 |
|
| 14m |
| 5.25 |
