Model | Band | Frequency (GHz) | Insertion Loss (dB) | Return Loss (dB) | Power Handling (W) | Waveguide Port | Coaxial Port |
410X/39/NF | X-Band | 8.2-12.4 | 0.4 | 16 | 400 | WR-90 Waveguide, UG-39/U Flange | NF- Female connector |
410X/39/SMAF | X-Band | 8.2-12.4 | 0.4 | 17 | 150 | WR-90 Waveguide, UG-39/U Flange | SMA- Female connector |
410X/39/SMAM | X-Band | 8.2-12.4 | 0.4 | 16 | 150 | WR-90 Waveguide, UG-39/U Flange | SMA-Male connector |
410(51)/UBR180/CKF | WR-51 | 15-12 | 0.3 | 20 | 10 | WR-51 Waveguide, UBR180 Flange w "O" Ring | CK-Female connector |
410(34)/596/KF | WR-34 | 22-33 | 0.4 | 20 | 10 | WR-34 Waveguide, UG-596 Flange w "O" Ring | K-Female connector |
410(34)/595/KF | WR-34 | 22-33 | 0.4 | 17 | 10 | WR-34 Waveguide, UG-596 Flange w "O" Ring | K-Female connector |
410(34)/595/3.5mmF | WR-35 | 22-33 | 0.4 | 20 | 10 | WR-34 Waveguide, UG-596 Flange w "O" Ring | 3.5 mm Female Connector |
410(75)/SMAF | WR-75 | 10-15 | 0.3 | 20 | 150 | WR-75 Waveguide | SMA Female |
410Ku/419/SMAF | Ku-Band | 12.4-18 | 0.3 | 20 | 150 | WR-62 Waveguide, UG-419 Flange | SMA Female |
410K/595/SMAF | K-Band | 18-26.5 | 0.4 | 20 | 150 | WR-42 Waveguide with UG-595/U Flange | SMA-Female |
410K/595/KF | K-Band | 18-26.5 | 0.4 | 20 | 10 | WR-42 Waveguide, UG-595/U Flange | K-Female connector |
410A/599/KF | Ka-Band | 26.5-40 | 0.4 | 20 | 10 | WR-28 Waveguide, UG-599/U Flange | K-Female connector |
410A/599/KM | Ka-Band | 26.5-40 | 0.4 | 20 | 10 | WR-28 Waveguide, UG-599/U Flange | K-Male connector |
410B/383/KF | Q-Band | 33-40 | 0.5 | 20 | 10 | WR-22 Waveguide with UG-383/U Flange | K-Female connector |
410B/383/KM | Q-Band | 33-40 | 0.4 | 20 | 10 | WR-22 Waveguide with UG-383/U Flange | 2.92mm (K) Male connector |
410B/383/2.4mmF | Q-Band | 33-50 | 0.4 | 20 | 10 | WR-22 Waveguide, UG-383/U Flange | 2.4 mm Female Connector |
410B/383/2.4mmM | Q-Band | 33-50 | 0.4 | 20 | 10 | WR-22 Waveguide, UG-383/U Flange | 2.4 mm Male Connector |
410U/383/1.85mmF | U-Band | 40-60 | 0.5 | 17 | 10 | WR-19 Waveguide with UG-383/U-M Flange | 1.85 mm Female connector |
410U/383/1.85mmM | U-Band | 40-60 | 0.5 | 17 | 10 | WR-19 Waveguide with UG-383/U-M Flange | 1.85 mm Male Connector |
410V/385/1.85mmF | V-Band | 50-67 | 0.5 | 17 | 10 | WR-15 Waveguide With UG-385/U Flange | 1.85 mm Female connector |
410V/385/1.85mmM | V-Band | 50-67 | 0.5 | 17 | 10 | WR-15 Waveguide with UG-385/U Flange | 1.85 mm Male connector |
410V/385/1.85mmF | V-Band | 50-67 | 0.5 | 17 | 10 | WR-15 Waveguide with UG-385/U Flange | 1.85 mm Female connector |
410V/385/1.00mmF | V-Band | 50-67 | 0.5 | 15 | 10 | WR-15 Waveguide with UG-385/U Flange | 1.00 mm Female connector |
410E/387/1.00mmM | E-Band | 60-90 | 1 | 15 | 10 | WR-12 Waveguide, UG-387/U Flange | 1.85 mm Male connector |
410E/387/1.00mmF | E-Band | 60-90 | 1 | 15 | 10 | WR-12 Waveguide, UG-387/U Flange | 1.00 mm Female connector |
410W/387/1.00mmM | W-Band | 75-110 | 1.2 | 15 | 10 | WR-10 Waveguide, UG-387/U-M Flange | 1.00 mm Male connector |
410W/387/1.00mmF | W-Band | 75-110 | 1.2 | 15 | 10 | WR-10 Waveguide, UG-387/U-M Flange | 1.00 mm Female connector |
