LINEAR LCD/CCD/OLED 偏置開關穩壓器
發布時間:2022-05-16 16:49:52 瀏覽:1162
LINEAR生產制造了門類寬泛的高性能開關穩壓器產品,專門用作在CCFL和LCD應用中形成偏置電壓。LCD/CCD/OLED偏置開關穩壓器具備0.9V至30V的經典輸入電壓性能、高達60V的輸出電壓、高達3MHz的開關頻率、高達1.5A的開關電流、及其多輸出性能。LCD/CCD/OLED偏置開關穩壓器性能組合提供了非常精巧的電路實現方案,并優化了電池配電型便攜式設備中的電池運作時間。
深圳市立維創展科技是ADI \ LINEAR的代理商,以代理分銷庫存現貨ADI \ LINEAR為產品優勢,可提供當日發貨服務,歡迎咨詢。
詳情了解LINEAR電源模塊請點擊:http://www.yzgnjsb.cn/brand/19.html
產品型號 | Number of Outputs | Vin (min) | Vin (max) | Boost Switch Current (typ) | Inverting Switch Current (typ) | Buck Output Current (typ) |
V | V | A | A | A | ||
ADP5072 | 2 | 2.85 | 5.5 | 1 | 600m | |
ADP5076 | 2 | 2.85 | 5.5 | 2 | 1.2 | |
ADP5070 | 2 | 2.85 | 15 | 1 | 600m | |
ADP5071 | 2 | 2.85 | 15 | 2 | 1.2 | |
LT8582 | 2 | 2.5 | 22 | 3, 3 | 4.3 | |
LT3579 | 1 | 2.5 | 16 | 7.5 | ||
LT3579-1 | 1 | 2.5 | 16 | 7.5 | ||
LT3581 | 1 | 2.3 | 22 | 4.3 | ||
LT3582 | 2 | 2.475 | 5.5 | 350m | 600m | |
LT3495 | 1 | 2.2 | 16 | 650m | ||
LT3495-1 | 1 | 2.2 | 16 | 350m | ||
LT3513 | 5 | 4.5 | 30 | 250m, 1.6 | 250m | 2.5 |
LT3587 | 3 | 2.5 | 6 | 20m, 50m | 100m | |
LT3580 | 1 | 2.5 | 32 | 2.5 | ||
LT3498 | 2 | 2.5 | 12 | 300m, 425m | ||
LTC3524 | 4 | 2.5 | 6 | 2m, 25m | 2m | |
LT3494 | 1 | 2.3 | 16 | 180m | ||
LT3494A | 1 | 2.3 | 16 | 350m | ||
LT3487 | 2 | 2.3 | 16 | 1.09 | 920m | |
LT3489 | 1 | 2.4 | 16 | 3.5 | ||
LT3466-1 | 2 | 2.7 | 24 | 400m | ||
LT1942 | 4 | 2.6 | 16 | 80m, 80m | ||
LT3471 | 2 | 2.4 | 16 | 1.3, 1.3 | 1.3 | |
LT3472 | 2 | 2.2 | 16 | 20m | 50m | |
LT3473 | 1 | 2.2 | 16 | 1.2 | ||
LT3473A | 1 | 2.2 | 16 | 1.2 | ||
LTC3459 | 1 | 1.5 | 5.5 | 75m | ||
LT3436 | 1 | 3 | 25 | 4 | ||
LT3461A | 1 | 2.5 | 16 | 420m | ||
LT3463 | 2 | 2.2 | 15 | 250m, 250m | 250m | |
LT3463A | 2 | 2.2 | 15 | 250m, 400m | 400m | |
LTC3450 | 3 | 1.4 | 4 | 10m | 500μ | |
LT3461 | 1 | 2.5 | 16 | 420m | ||
LT3467 | 1 | 2.2 | 16 | 1.1 | ||
LT3467A | 1 | 2.2 | 16 | 1.1 | ||
LT3460 | 1 | 2.5 | 16 | 420m | ||
LT1943 | 4 | 4.5 | 22 | 350m, 2.6 | 350m | 2.4 |
LTC1697 | 1 | 2.8 | 5.5 | 1.6 | ||
LT3464 | 1 | 2 | 10 | 80m | ||
LT1944-1 | 2 | 1.2 | 15 | 100m, 175m | ||
LT1945 | 2 | 1.2 | 15 | 350m | 350m | |
LT1946 | 1 | 2.45 | 16 | |||
LT1947 | 3 | 2.7 | 8 | 1.1 | 10m | |
LT1618 | 1 | 1.6 | 18 | 2 | ||
LT1944 | 2 | 1.2 | 15 | 350m, 350m | ||
LT1768 | 1 | 8 | 24 | 1.5 | ||
LT1931 | 1 | 2.6 | 16 | 1.2 | ||
LT1931A | 1 | 2.6 | 16 | 1.2 | ||
LT1930 | 1 | 2.45 | 16 | 1.2 | ||
LT1930A | 1 | 2.45 | 16 | 1.2 | ||
LT1617 | 1 | 1.2 | 15 | 350m | ||
LT1617-1 | 1 | 1 | 15 | 100m | ||
LT1308A | 1 | 1 | 10 | 3 | ||
LT1308B | 1 | 1 | 10 | 3 | ||
LT1613 | 1 | 900m | 10 | 800m | ||
LT1611 | 1 | 1.1 | 10 | 800m | ||
LT1316 | 1 | 1.5 | 12 | 500m | ||
LT1317 | 1 | 1.5 | 12 | 800m | ||
LT1317B | 1 | 1.5 | 12 | 800m | ||
LT1307 | 1 | 920m | 12 | 600m | ||
LT1307B | 1 | 920m | 12 | 600m |
