ADI標準高速模數轉換器>20 MSPS
發布時間：2022-03-03 17:34:35 瀏覽：1757
ADI的高速模數轉換器(ADC)提供行業市場上較佳的性能指標和較高的采樣速率。ADI標準高速模數轉換器產品包括低中頻模數轉換器（20MSPS至125MSPS）、高中頻模數轉換器(125MSPS至1.3GSPS）和寬帶ADC(>1GSPS)。高速模數轉換器產品系列為通信基礎設施、電子測試與測量、航空航天與防御等各種應用提供成本和性能優化的解決方案。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.yzgnjsb.cn/brand/25.html
*如需了解更多型號請聯系我們！
產品型號 | Channels | Resolution | Sample Rate (max) | ADC SNR in dBFS (typ) | INL in LSB (typ) | Vin Range (typ) | Power (typ) |
|
| bits | SPS | dBFS | LSBs | V p-p | W |
AD9257S | 8 | 14 | 65M | 75.7 | 1.1 | 2 | 464m |
AD9207 | 2 | 12 | 6G | 53.4 | 1.38 | 1.475 | 5.6 |
AD9209 | 4 | 12 | 4G | 55.9 | 0.5 | 1.4 | 5.47 |
AD9699 | 1 | 14 | 3G | 60.2 | 6 | 1.54 | 2 |
AD9213S | 1 | 12 | 10.25G | 57.5 | 2.4 | 1.4 | 5.1 |
AD9083 | 16 | 14 | 2G | 66 |
| 0.5 | 1.45 |
AD9094 | 4 | 8 | 1G | 49.2 |
| 1.44 | 1.6 |
AD9213 | 1 | 12 | 10.25G | 57.5 | 2.4 | 1.4 | 5.1 |
AD9697 | 1 | 14 | 1.3G | 65.6 | 1 | 1.59 | 1.01 |
LTM2173-14 | 4 | 14 | 80M | 73 | 1 | 2 | 385m |
AD9689-2000 | 2 | 14 | 2G | 62.7 | 2 | 1.59 | 2.5 |
AD9689-2600 | 2 | 14 | 2.6G | 61.3 | 6 | 1.59 | 3.1 |
AD9695-1300 | 2 | 14 | 1.3G | 65.6 | 1 | 1.59 | 1.6 |
AD9695-625 | 2 | 14 | 625M | 67.2 | 2 | 1.59 | 980m |
AD9246S | 1 | 14 | 125M | 71.9 | 1.5 | 2 | 458m |
AD9208 | 2 | 14 | 3G | 60.2 | 6 | 1.7 | 3.3 |
AD9694 | 4 | 14 | 500M | 67.1 | 1 | 1.8 | 1.66 |
AD9691 | 2 | 14 | 1250M | 63.4 | 2.6 | 1.58 | 3.8 |
AD9684 | 2 | 14 | 500M | 69.2 | 2.5 | 2.06 | 2.2 |
AD9655 | 2 | 16 | 125M | 79.6 | 4 | 2.8 | 313m |
AD9690-1000 | 1 | 14 | 1G | 67.2 | 2.5 | 1.7 | 2 |
AD9690-500 | 1 | 14 | 500M | 69.2 | 2.5 | 2.06 | 1.5 |
LTC2122 | 2 | 14 | 170M | 70 | 1.2 | 1.5 | 751m |
LTC2123 | 2 | 14 | 250M | 70 | 0.85 | 1.5 | 864m |
AD8285 | 4 | 12 | 72M | 68 |
| 0.25 | 185m |
AD9234-1000 | 2 | 12 | 1G | 64.2 | 35 | 1.34 | 3 |
AD9234-500 | 2 | 12 | 500M | 65.9 |
| 1.63 | 2.15 |
HMCAD5831 | 1 | 3 | 26G | 19.2 | 0.3 | 0.256 | 4.2 |
LTC2107 | 1 | 16 | 210M | 79.8 | 1.6 | 2.5 | 1.28 |
AD9625-2000 | 1 | 12 | 2G | 59.5 | 0.9 | 1.1 | 3.48 |
AD9625-2500 | 1 | 12 | 2.5G | 58.3 | 1 | 1 | 3.9 |
AD9625-2600 | 1 | 12 | 2.6G | 58.1 | 1 | 1 | 4 |
AD9652 | 2 | 16 | 310M | 75.4 | 4.5 | 2.5 | 2160m |
AD9680-1000 | 2 | 14 | 1G | 67.2 | 2.5 | 1.7 | 3.3 |
AD9680-1250 | 2 | 14 | 1.25G | 63.6 | 3 | 1.58 | 3.7 |
AD9680-500 | 2 | 14 | 500M | 69.2 | 2.5 | 2.06 | 2.2 |
AD9680-820 | 2 | 14 | 820M | 67.2 | 2.5 | 1.7 | 2.9 |
AD9656 | 4 | 16 | 125M | 80.1 | 4.5 | 2.8 | 788m |
AD9249 | 16 | 14 | 65M | 75.4 | 0.9 | 2 | 924m |
AD9671 | 8 | 14 | 125M | 75 |
| 1 | 1.2 |
AD9675 | 8 | 14 | 125M | 75 |
| 1 | 1.2 |
AD9681 | 8 | 14 | 125M | 74.8 | 1.2 | 2 | 879m |
LTM9013 | 2 | 14 | 310M | 59 | 4.5 | 1.3 | 2.6 |
AD9674 | 8 | 14 | 125M | 69 |
| 1.2 | 1.515 |
AD9683-170 | 1 | 14 | 170M | 72.3 | 0.8 | 1.75 | 365m |
AD9683-250 | 1 | 14 | 250M | 72.1 | 1.5 | 1.75 | 434m |
LTC2271 | 2 | 16 | 20M | 84.1 | 1 | 2.1 | 185m |
LTM9006-14 | 8 | 14 | 25M | 72.9 | 1 | 2 | 369m |
LTM9007-14 | 8 | 14 | 40M | 73.5 | 1 | 2 | 475m |
LTM9008-14 | 8 | 14 | 65M | 73.7 | 1.2 | 2 | 700m |
AD9670 | 8 | 14 | 125M | 69 |
| 1.2 | 1.535 |
AD8284 | 4 | 12 | 60M | 68 | 4 | 0.25 | 345m |
AD9250-170 | 2 | 14 | 170M | 72.5 | 1.5 | 1.75 | 607m |
AD9250-250 | 2 | 14 | 250M | 72.1 | 1.5 | 1.75 | 711m |
LTC2269 | 1 | 16 | 20M | 84.1 | 1 | 2.1 | 88m |
LTC2270 | 2 | 16 | 20M | 84.1 | 1 | 2.1 | 160m |
AD9635 | 2 | 12 | 80M | 71 | 0.4 | 2 | 115m |
AD9645-125 | 2 | 14 | 125M | 75.2 | 1.5 | 2 | 243m |
AD9645-80 | 2 | 14 | 80M | 75.6 | 1.1 | 2 | 187m |
LTC2159 | 1 | 16 | 20M | 77.1 | 2 | 2 | 43m |
LTC2188 | 2 | 16 | 20M | 77.1 | 2 | 2 | 76m |
LTC2201 | 1 | 16 | 20M | 81.6 | 1.5 | 2.5 | 211m |
LTM9012 | 4 | 14 | 125M | 68.3 | 1.2 | 3.6 | 1.27 |
AD9653 | 4 | 16 | 125M | 78 | 3.5 | 2 | 657m |
