ADI電流反饋運算放大器
發布時間：2021-07-28 16:48:36 瀏覽：1302
ADI高速(>50MHz)電流反饋運算放大器能以更好的效率運作。與電流電壓信息反饋放大器相比較，電流反饋運算放大器的帶寬更寬，壓擺率更好，而且不存在電流電壓信息反饋放大器相應的增益帶寬限制。電流反饋運算放大器在其低特性阻抗負輸入端響應誤差工作電流，而不是誤差電流電壓，并形成相應的輸出電壓。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.yzgnjsb.cn/brand/25.html
或聯系ADI的銷售工程師： 0755- 83642657 QQ： 2295048674
產品型號 | # of Amps | BW -3 dB (typ) | Slew Rate (typ) | Ibias (max) | VNoise Density (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | A | V/rtHz | A | V | V |
LT1210X | 1 | 55M | 900 |
| 3n | 35m | 10 | 30 |
ADA4870 | 1 | 52M | 2.5k | 23μ | 2.1n | 32.5m | 10 | 40 |
ADA4312-1 | 2 | 195M | 2.1k | 175μ | 57n | 46m | 12 | 12 |
ADA4858-3 | 3 | 600M | 600 | 13μ | 4n | 19m | 3 | 5.5 |
ADA4859-3 | 3 | 265M | 740 | 2μ | 17n | 5.7m | 3 | 5.5 |
ADA4311-1 | 2 | 310M | 1.05k | 16μ | 2.4n | 11.8m | 12 | 12 |
AD8392A | 4 | 37M | 515 | 10μ | 2.5n | 5.8m | 10 | 24 |
ADA4310-1 | 2 | 190M | 820 |
| 2.85n | 7.6m | 5 | 12 |
LT6559 | 3 | 300M | 500 |
| 4.5n | 3.9m | 4 | 12 |
ADA4860-1 | 1 | 800M | 790 | 10μ | 4n | 6m | 5 | 12 |
AD8003 | 3 | 1.65G | 3.8k | 50μ | 1.8n | 9.5m | 4.5 | 10 |
ADA4861-3 | 3 | 730M | 680 | 13μ | 3.2n | 16.1m | 5 | 12 |
ADA4862-3 | 3 | 720M | 830 | 1μ | 10.6n | 16m | 5 | 12 |
AD8000 | 1 | 1.58G | 4.1k | 45μ | 1.6n | 13.5m | 4.5 | 12 |
LT6210 | 1 | 200M | 700 |
| 6.5n | 5.8m | 3 | 13.2 |
LT6211 | 2 | 200M | 700 |
| 6.5n | 5.8m | 3 | 13.2 |
AD8008 | 2 | 500M | 1k | 8μ | 2.7n | 9m | 5 | 12 |
AD8007 | 1 | 500M | 1k | 6μ | 2.7n | 9m | 5 | 12 |
AD8018 | 2 | 130M | 300 | 8μ | 4.5n | 9m | 3.3 | 8 |
LT1395 | 1 | 400M | 800 |
| 4.5n | 4.6m | 3 | 12.6 |
AD8024 | 4 | 200M | 390 | 7.5μ | 3n | 17m | 5 | 24 |
LT1397 | 4 | 400M | 800 |
| 4.5n | 4.6m | 3 | 12.6 |
LT1396 | 2 | 400M | 800 |
| 4.5n | 4.6m | 3 | 12.6 |
AD8016 | 2 | 380M | 1k | 75μ | 2.6n | 12.5m | 6 | 26 |
LT1795 | 2 | 65M | 900 |
| 3.6n | 29m | 10 | 36 |
LT1398 | 2 | 300M | 800 |
| 4.5n | 4.6m | 3 | 12.6 |
AD8014 | 1 | 480M | 4.6k | 15μ | 3.5n | 1.15m | 4.5 | 12 |
AD8017 | 2 | 160M | 1.6k | 45μ | 1.9n | 7m | 4.4 | 12 |
LT1399 | 3 | 300M | 800 |
| 4.5n | 4.6m | 3 | 12.6 |
LT1399HV | 3 | 300M | 800 |
| 4.5n | 4.6m | 3 | 15.5 |
AD8010 | 1 | 230M | 800 | 135μ | 2n | 15.5m | 9 | 12 |
AD8012 | 2 | 350M | 2.25k | 12μ | 2.5n | 1.7m | 3 | 12 |
AD8023 | 3 | 125M | 1.2k | 45μ | 2n | 6.2m | 4.2 | 15 |
LT1497 | 2 | 59M | 900 |
| 3n | 6m | 4 | 36 |
AD8005 | 1 | 270M | 1.5k | 10μ | 4n | 400μ | 8 | 12 |
AD8009 | 1 | 1G | 5.5k | 150μ | 1.9n | 14m | 5 | 12 |
AD8072 | 2 | 100M | 500 | 12μ | 3n | 3m | 5 | 12 |
AD8073 | 3 | 100M | 500 | 12μ | 3n | 3m | 5 | 12 |
LT1210 | 1 | 66M | 900 |
| 3n | 35m | 8 | 36 |
AD815 | 2 | 120M | 900 | 5μ | 1.85n | 15m | 10 | 36 |
LT1207 | 2 | 66M | 900 |
| 3.6n | 20m | 10 | 36 |
AD8004 | 4 | 250M | 3k | 110μ | 1.5n | 14m | 4 | 12 |
AD8013 | 3 | 140M | 1k | 15μ | 3.5n | 3.5m | 4.2 | 13 |
AD8002 | 2 | 600M | 1.2k | 25μ | 2n | 10m | 6 | 12 |
AD8011 | 1 | 400M | 1.1k | 15μ | 2n | 1m | 3 | 12 |
AD8001 | 1 | 880M | 1.2k | 25μ | 2n | 5m | 6 | 12 |
AD8001S | 1 | 880M |
| 25μ |
|
| 6 | 12 |
LT1251 | 1 | 40M | 300 | 30μ | 2.7n | 13.5m | 5 | 36 |
LT1256 | 1 | 40M | 300 |
| 2.7n | 13.5m | 5 | 36 |
AD812 | 2 | 145M | 250 | 25μ | 3.5n | 4.5m | 2.4 | 36 |
AD813 | 3 | 100M | 450 | 30μ | 3.5n |
| 2.4 | 36 |
LT1204 | 1 | 95M | 1k |
| 7n | 19m | 9 | 36 |
LT1259 | 2 | 130M | 1.6k |
| 3.6n | 5m | 4 | 36 |
LT1260 | 3 | 130M | 1.6k |
| 3.6n | 5m | 4 | 36 |
LT1206 | 1 | 66M | 900 |
| 3.6n | 20m | 10 | 36 |
LT1252 | 1 | 250M | 250 |
| 3n | 8.5m | 4 | 28 |
LT1253 | 2 | 250M | 250 |
| 3n | 6m | 4 | 28 |
AD810 | 1 | 80M | 1k | 10μ | 2.9n | 6.8m | 5 | 36 |
LT1217 | 1 | 10M | 500 |
| 6.5n | 1m | 10 | 36 |
LT1227 | 1 | 140M | 1.1k |
| 3.2n | 10m | 4 | 36 |
LT1227MJ8 | 1 |
| 1.1k |
| 3.2n | 10m | 4 | 36 |
AD811 | 1 | 140M | 400 | 5μ | 1.9n | 14.5m | 9 | 36 |
LT1228 | 1 | 100M | 500 | 1μ | 20n | 9m | 4 | 36 |
LT1229 | 2 | 100M | 700 |
| 3.2n | 6m | 4 | 36 |
LT1230 | 4 | 100M | 700 |
| 3.2n | 6m | 4 | 36 |
LT1223 | 1 | 100M | 1k |
| 33n | 6m | 5 | 36 |
AD844 | 1 | 60M | 2k | 250n | 2n | 6.5m | 9 | 36 |
AD844S | 1 | 60M |
| 450n |
|
| 9 | 36 |
