ADI低噪聲放大器
發布時間：2021-04-16 15:20:14 瀏覽：1459
ADI低噪聲放大器能夠 覆蓋從直流電壓(IF)到射頻微波和W波段(95GHz)的頻率使用范圍。這種依托于MMIC的設計涵蓋了各種各樣增益值和帶寬，噪聲系數低至0.7dB。ADI的低噪聲放大器提供了行業內現有的最低噪聲和最高線性度。許多設計提供內部結構匹配至50Ω的自偏置拓撲。ADI低噪聲放大器可廣泛運用于電信、儀器設備和軍事/航空航天行業領域。所有的ADI低噪聲放大器在整個頻率、工作溫度和電源電壓使用范圍內都提供額定性能指標。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
詳情了解ADI芯片請點擊：http://www.yzgnjsb.cn/brand/25.html
或聯系我們的銷售工程師： 0755- 83642657 QQ： 2295048674
*詳情了解更多ADI芯片請聯系我們的銷售工程師。
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | OP1dB (typ) | OIP3 (typ) | NF (typ) | Vs (typ) | Is (typ) |
| Hz | Hz | dB | dBm | dBm | dB | V | A |
ADCA3950 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADL8104 | 400M | 7.5G | 15 | 20 | 32 | 3.5 | 5 | 150m |
ADCA3952 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
HMC8412-Die | 400M | 10G | 15 | 19 | 32 | 1.5 | 5 | 60m |
HMC8412LP2FE | 400M | 11G | 15 | 18 | 33 | 1.5 | 5 | 60m |
ADL9005 | 10M | 26.5G | 18.5 | 13.5 | 25 | 2.5 | 5 | 80m |
ADL9006-Die | 2G | 28G | 15.5 | 17 | 21 | 2.5 | 5 | 55 |
ADL9006ACGZN | 2G | 28G | 15.5 | 18 | 23 | 2.5 | 5 | 53m |
ADH519S | 17.5G | 31.5G | 11 | 7.2 | 17.2 | 4 | 3 | 95m |
ADL8111 | 10M | 8G | 12.5 | 19.5 | 34 | 2.8 | 5 | 70m |
HMC8411 | 10M | 10G | 15 | 20 | 34 | 1.7 | 5 | 55m |
ADCA3990 | 45M | 1.218G | 24.5 |
|
| 4 | 34 | 535m |
ADCA3992 | 45M | 1.218G | 26 |
|
| 4 | 34 | 535m |
ADL7003 | 50G | 95G | 14 | 14 | 21 | 5.5 | 3 | 120m |
HMC8325 | 71G | 86G | 21 | 13 | 22 | 3.6 | 3 | 50m |
HMC392A-Die | 3.5G | 7G | 17.2 | 19 | 32.5 | 1.7 | 5 | 59m |
HMC392ALC4 | 3.5G | 8G | 17 | 19 | 34.5 | 1.8 | 5 | 61m |
HMC7950 | 2G | 28G | 15 | 16 | 26 | 2 | 5 | 64m |
HMC717A | 4.8G | 6G | 14.5 | 18 | 29.5 | 1.3 | 5 | 73m |
HMC8401-Die | 10M | 28G | 14.5 | 16.5 | 26 | 1.5 | 7.5 | 60m |
HMC8402-Die | 2G | 30G | 13.5 | 20 | 24 | 2.5 | 7 | 68m |
HMC8410-Die | 10M | 10G | 18 | 20.5 | 31.5 | 1.4 | 5 | 65m |
HMC8410LP2FE | 10M | 10G | 18 | 21 | 31.5 | 1.4 | 5 | 65m |
ADL5721 | 5.9G | 8.5G | 25.9 | -9.3 | 4 | 1.6 | 3.3 | 86.5m |
ADL5723 | 10.1G | 11.7G | 24.5 | -10 | 2.2 | 2.2 | 3.3 | 109.1m |
ADL5724 | 12.7G | 15.4G | 26.4 | -11 | 2 | 2.1 | 3.3 | 109.7m |
ADL5725 | 17.7G | 19.7G | 27.8 | -14 | -1.5 | 2.4 | 3.3 | 108m |
ADL5726 | 21.2G | 23.6G | 24.7 | -9.5 | 1 | 3.3 | 3.3 | 92.4m |
HMC8400-Die | 2G | 30G | 14 | 14.5 | 25 | 2 | 5 | 67m |
ADA8282 | 0 | 42.3M | 18 |
|
|
| 3.3 | 19.6m |
HMC1127 | 2G | 50G | 14 | 12 | 22 | 6 | 5 | 65m |
HMC1126 | 2G | 50G | 11 | 16 | 28 | 4 | 5 | 66m |
HMC1049-Die | 0.3G | 20G | 16 | 13 | 25 | 2 | 7 | 70m |
HMC1049LP5E | 0.3G | 20G | 15 | 14.5 | 29 | 1.8 | 7 | 70m |
HMC1040-Die | 20G | 44G | 21 | 14 | 25.5 | 2.5 | 2.5 | 65m |
HMC1040LP3CE | 24G | 43.5G | 20 | 12 | 24 | 2.7 |
| 70m |
HMC902-Die | 5G | 11G | 20 | 16 | 28 | 1.6 | 3.5 | 80m |
HMC902LP3E | 5G | 11G | 19 | 16 | 28 | 1.8 | 3.5 | 80m |
