LINEAR電源能量收集超低功率 IC
發布時間：2021-02-01 17:12:40 瀏覽：2673
LINEAR電源模塊提供多種多樣面向能量收集應用領域的超低功率IC。適用于對來自震動能源(壓電式)、光伏能源(太陽能)和熱能源(TEC、TEG、熱電堆、熱電阻)的能量實現轉換的電源管理產品提供高效率轉換至穩壓電流電壓，或對電池和超級電容器存儲元件實現充電。LINEAR電源模塊能量收集可在低至20mV的電流電壓條件下工作的升壓型轉換器或具備最大功率點工作能力的電池充電器為工業自動化和調節、無線傳感器、交通運輸、車輛以及樓房管理應用領域拓展了概率。LINEAR電源模塊能量收集超低靜態電流線性穩壓器、運算放大器、比較器、電流電壓監控器、ADC、DAC和微功率基準電流電壓提供了適用于自主型系統的附加組件。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.yzgnjsb.cn/brand/19.html
或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674
產品型號 | Number of Outputs | Energy Source | Topology | Vin (min) | Vin (max) |
|
|
|
| V | V |
LT8491 | 1 | Solar | Buck-Boost | 6 | 80 |
LTC4162-F | 1 |
| Buck | 4.5 | 35 |
LTC4162-L | 1 |
| Buck | 4.5 | 35 |
LTC4162-S | 1 |
| Buck | 4.5 | 35 |
LTC3130 | 1 | Solar | Buck-Boost | 2.4 | 25 |
LTC4013 | 1 | Solar | Buck | 4.5 | 60 |
ADP5091 | 1 | Piezoelectric, Solar, Thermoelectric |
| 80m | 3.3 |
ADP5092 | 1 | Piezoelectric, Solar, Thermoelectric |
| 80m | 3.3 |
LTC3119 | 1 | Solar | Buck-Boost | 250m | 18 |
LTC3106 | 1 | Solar, Thermoelectric | Buck-Boost | 850m | 5.1 |
LTC4015 | 1 | Solar | Buck | 4.5 | 35 |
ADP5090 | 1 |
|
| 80m | 3.3 |
LTC4121 | 1 | Solar | Buck Battery Charger | 4.4 | 40 |
LTC4121-4.2 | 1 | Solar | Buck Battery Charger | 4.4 | 40 |
LT8490 | 1 | Solar | Buck-Boost | 6 | 80 |
LTC3331 | 1 | Magnetic, Piezoelectric, Solar | Buck-Boost | 3 | 19 |
LTC3107 | 3 | Thermoelectric | Boost, LDO | 20m | 500m |
LTC3129 | 1 |
| Buck-Boost | 1.92 | 15 |
LTC3129-1 | 1 |
| Buck-Boost | 1.92 | 15 |
LTC3330 | 2 | Magnetic, Piezoelectric, Solar | Buck-Boost | 3 | 18 |
LTC4020 | 1 | Solar |
| 4.5 | 55 |
LTC4000-1 | 1 | Solar | Buck | 3 | 60 |
LTC3103 | 1 |
| Buck | 2.5 | 15 |
LTC3104 | 2 |
| Buck, LDO | 2.5 | 15 |
LTC4071 | 1 |
| Shunt Battery Charger | 2.65 |
|
LTC3109 | 3 | Thermoelectric | Boost | 20m | 500m |
LTC3388 | 1 |
| Buck | 2.7 | 20 |
LTC3588-2 | 1 | Piezoelectric | Buck | 14 | 20 |
LTM8062 | 1 | Solar | Buck | 4.95 | 32 |
LTM8062A | 1 | Solar | Buck | 4.95 | 32 |
LT3652HV | 1 | Solar | Buck | 4.95 | 34 |
LTC3108-1 | 3 | Thermoelectric | Boost, LDO | 20m | 500m |
LTC3105 | 1 | Solar | Boost | 200m | 5 |
LT3652 | 1 | Solar | Battery Charger | 4.95 | 32 |
LTC3108 | 3 | Thermoelectric | Boost, LDO | 20m | 500m |
LTC3535 | 2 |
| Boost | 500m | 5 |
LTC3588 | 1 | Piezoelectric | Buck | 2.7 | 20 |
LTC4070 | 1 |
| Shunt Battery Charger | 3.1 |
|
LTC3534 | 1 |
| Buck-Boost | 2.4 | 7 |
LTC3526L | 1 |
| Boost | 500m | 5 |
