ADI芯片中ADC驅動器的作用是什么？
發布時間：2020-07-15 15:22:18 瀏覽：4571
ADI是世界當先的模擬芯片、混合信號和數字信號處分技術品牌，其產品寬泛軟件于航空航天、工業、汽車、通訊和消費類電子產品市場。
ADI單差和全差ADC驅動用具有精確的直流規格，通過它們的差分輸入和輸出布局，可以更好地抑制高頻PSRR和CMRR。
ADI模數轉換器驅動器采用VOCM引腳實現精度和高速差分擴大器，為持續模數轉換器(ADC)提供了環節和利便的辦理計劃。通過ADC輸入的采樣電路迅速消除了發送到擴大器輸出的大批攪擾能量，從而實現了任何ADC驅動器的環節機能。ADI曾經開發了范圍寬泛的高速差動擴大器產品，無論您需求驅動單差分或雙差輸入ADC，還是通過長電纜發送和接收信號，響應的產品提供了滿足任何要求的高機能產品。
差分輸入和輸出還可以通過低落ADC接收到的總諧波失真來改善系統。
深圳市立維創展科技是ADI芯片的代理商。ADI芯片產品提供：擴大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和按時IC、光纖和光纖通訊產品、接口和斷絕、MEMS和傳感器、電源和熱經管、處分器和DSP、射頻和圖形處分器、開關和分路器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
詳情了解ADI芯片請點擊：http://www.yzgnjsb.cn/brand/25.html
或聯系我們的銷售工程師：0755-83642657 QQ: 1369964087
產品型號 | BW -3 dB (typ) | Slew Rate (typ) | Gain Set | Gain (min) | Gain (max) | Is (typ) | Vs span (min) | Vs span (max) |
| Hz | V/us |
| dB | dB | A | V | V |
ADA4945-1 | 200M | 600 | Resistor |
|
| 4m | 2.7 | 11 |
ADL5569 | 6.5G | 24k | Pin Strap | 6 | 20 | 86m | 4.75 | 5.25 |
LTC6432A-15 | 1.4G |
| Fixed | 15.2 | 15.2 | 166m | 4.75 | 5.25 |
LTC6432B-15 | 1.4G |
| Fixed | 15.2 | 15.2 | 166m | 4.75 | 5.25 |
LTC6419 | 1.4G | 3.3k | Resistor | 0 |
| 52m | 2.7 | 5.25 |
ADL5567 | 4.3G | 20000 | Pin Strap | 0 | 20 | 138m | 3.15 | 5.25 |
ADL5205 | 1.2G | 5000 | Digital | -9 | 26 | 175m | 3.15 | 5.25 |
LTC6363 | 35M | 75 | Resistor | -20 |
| 1.7m | 2.8 | 11 |
LTC6363-0.5 | 60M | 75 | Fixed | -6.02 | -6.02 | 1.7m | 2.8 | 11 |
LTC6363-1 | 35M | 75 | Fixed | 0 | 0 | 1.7m | 2.8 | 11 |
LTC6363-2 | 21M | 75 | Fixed | 6.02 | 6.02 | 1.7m | 2.8 | 11 |
ADA4961 | 3.2G | 12k | Digital, Pin Strap | -6 | 15 | 150m | 3.3 | 5.5 |
LTC6430A-20 | 2G |
| Fixed | 20.8 | 20.8 | 170m | 4.75 | 5.25 |
LTC6430B-20 | 2G |
| Fixed | 20.8 | 20.8 | 170m | 4.75 | 5.25 |
LTC6430A-15 | 2G |
| Fixed | 15.2 | 15.2 | 160m | 4.75 | 5.25 |
LTC6430B-15 | 2G |
| Fixed | 15.2 | 15.2 | 160m | 4.75 | 5.25 |
ADL5566 | 4.5G | 20k | Pin Strap | 3 | 16 | 160m | 2.8 | 5.2 |
LTC6417 | 1.6G | 10k | Fixed | 0 | 0 | 123m | 4.75 | 5.25 |
LTC6362 | 34M | 45 | Resistor | 0 | 0 | 900μ | 2.8 | 5.25 |
AD8476 | 6M | 10 | Fixed | 1 | 1 | 330μ | 3 | 18 |
ADA4940-1 | 260M | 95 | Resistor |
|
| 1.25m | 3 | 7 |
ADA4940-2 | 260M | 95 | Resistor |
|
| 1.25m | 3 | 7 |
ADL5565 | 6G | 11000 | Pin Strap | 0 | 15.5 | 80m | 2.8 | 5.2 |
LTC6360 | 250M | 135 | Resistor | 0 |
| 6.6m | 4.75 | 5.25 |
AD8366 | 600M | 1.1k | Digital | 4.5 | 20.25 | 180m | 4.75 | 5.25 |
AD8475 | 150M | 50 | Digital, Pin Strap | -8 | -2 | 3m | 3 | 10 |
ADA4930-1 | 1.4G | 2.8k | Resistor |
|
| 35m | 3.3 | 5 |
ADA4930-2 | 1.4G | 2.8k | Resistor |
|
| 70m | 3.3 | 5 |
LTC6409 | 2G | 3.3k | Resistor | 0 |
| 52m | 2.7 | 5.25 |
ADA4960-1 | 5G | 8.7k | Analog | 0 | 18 | 60m | 4.75 | 5.25 |
LT6350 | 33M | 48 | Resistor |
|
| 4.8m | 2.7 | 12 |
ADA4950-1 | 750M | 2.9k | Digital, Pin Strap | 0 | 9.54 | 9.5m | 3 | 11 |
ADA4950-2 | 750M | 2.9k | Digital, Pin Strap | 0 | 9.54 | 19m | 3 | 11 |
ADL5561 | 2.9G | 9.8k | Pin Strap | 3 | 15.5 | 40m | 3 | 3.6 |
ADL5562 | 3.3G | 9.8k | Pin Strap | 3 | 15.5 | 80m | 3 | 3.6 |
LTC6412 | 800M |
| Analog | -14 | 17 | 110m | 3 | 3.6 |
ADA4927-1 | 2.3G | 5k | Resistor |
|
| 22.1m | 4.5 | 11 |
ADA4927-2 | 2.3G | 5k | Resistor |
|
| 44.2m | 4.5 | 11 |
ADA4932-1 | 560M | 2.8k | Resistor |
|
| 9.6m | 3 | 11 |
ADA4932-2 | 560M | 2.8k | Resistor |
|
| 19.2m | 3 | 11 |
LTC6416 | 2G | 3.4k | Fixed | 0 | 0 | 42m | 2.7 | 3.9 |
ADA4939-1 | 1.4G | 6.8k | Resistor |
|
| 37.7m | 3 | 5.25 |
ADA4939-2 | 1.4G | 6.8k | Resistor |
|
| 75.4m | 3 | 5.25 |
LT6604-10 | 10M |
| Resistor | 0 |
| 35m | 3 | 11 |
LT6604-15 | 15M |
| Resistor | 0 |
| 35m | 3 | 11 |
LT6604-2.5 | 2.5M |
| Resistor | 0 |
| 26m | 3 | 11 |
LT6604-5 | 5M |
| Resistor | 0 |
| 26m | 3 | 11 |
LTC6400-14 | 2.4G | 6k | Fixed | 14 | 14 | 85m | 2.85 | 3.5 |
LTC6400-20 | 1.8G | 4.5k | Fixed | 20 | 20 | 90m | 2.85 | 3.5 |
LTC6400-8 | 2.2G | 3.81k | Fixed | 8 | 8 | 85m | 2.85 | 3.5 |
LTC6405 | 800M | 690 | Resistor | 0 |
| 18m | 4.5 | 5.25 |
LTC6421-20 | 1.3G | 4.5k | Fixed | 20 | 20 | 40m | 2.85 | 3.5 |
LTC6420-20 | 1.8G | 4.5k | Fixed | 20 | 20 | 80m | 2.85 | 3.5 |
AD8372 | 130M |
| Digital | -9 | 32 | 212m | 4.5 | 5.5 |
ADA4937-2 | 1.9G | 6k | Resistor |
|
| 80m | 3 | 5.25 |
ADA4938-1 | 1G | 4.7k | Resistor |
|
| 40m | 4.5 | 11 |
ADA4938-2 | 1G | 4.7k | Resistor |
|
| 80m | 4.5 | 11 |
LTC6401-8 | 2.2G | 3.4k | Fixed | 8 | 8 | 45m | 2.85 | 3.5 |
LTC6403-1 | 200M | 200 | Resistor | 0 |
| 10.8m | 2.7 | 5.25 |
AD8375 | 630M | 5k | Digital | -4 | 20 | 125m | 4.5 | 5.5 |
AD8376 | 700M | 5k | Digital | -4 | 20 | 250m | 4.5 | 5.5 |
LTC6400-26 | 1.9G | 6.67k | Fixed | 26 | 26 | 85m | 2.85 | 3.5 |
LTC6401-26 | 1.6G | 3.3k | Fixed | 26 | 26 | 45m | 2.85 | 3.5 |
LTC6404-1 | 600M | 450 | Resistor | 0 |
| 27.2m | 2.7 | 5.5 |
LTC6404-2 | 600M | 700 | Resistor | 6 |
| 29.7m | 2.7 | 5.5 |
LTC6404-4 | 530M | 1.2k | Resistor | 12 |
| 30m | 2.7 | 5.5 |
LTC6410-6 | 1.4G | 1.5k | Fixed | 6 | 6 | 104m | 2.8 | 5.5 |
ADA4937-1 | 1.9G | 6k | Resistor |
|
| 39.5m | 3 | 5.25 |
LTC6401-20 | 1.3G | 4.5k | Fixed | 20 | 20 | 50m | 2.85 | 3.5 |
LTC6406 | 800M | 630 | Resistor | 0 |
| 18m | 2.7 | 3.5 |
LTC6401-14 | 2G | 3.6k | Fixed | 14 | 14 | 45m | 2.85 | 3.5 |
AD8368 | 800M |
| Analog | -12 | 22 | 60m | 4.75 | 5.5 |
ADA4941-1 | 31M | 22 | Analog |
|
| 2.3m | 2.7 | 12 |
LT6402-12 | 300M | 400 | Fixed | 12 | 12 | 30m | 4 | 5.5 |
LT6402-6 | 300M | 400 | Fixed | 6 | 6 | 30m | 4 | 5.5 |
LT6411 | 650M | 3.3k | Pin Strap | 0 | 6 | 16m | 4.5 | 12.6 |
AD8352 | 2.2G | 9k | Analog | 3 | 25 | 37m | 3 | 5.5 |
ADA4922-1 | 38M | 730 | Fixed | 6 | 6 | 9.4m | 5 | 26 |
LT6600-15 | 15M |
| Resistor | 0 |
| 46m | 2.7 | 11 |
LT1993-10 | 700M | 1.1k | Fixed | 20 | 20 | 100m | 4 | 5.5 |
LT1993-2 | 800M | 1.1k | Fixed | 6 | 6 | 100m | 4 | 5.5 |
LT1993-4 | 900M | 1.1k | Fixed | 12 | 4 | 100m | 4 | 5.5 |
LT1994 | 70M | 65 | Resistor | 0 |
| 13.3m | 2.375 | 12.6 |
LT6402-20 | 300M | 400 | Fixed | 20 | 20 | 30m | 4 | 5.5 |
LT5524 | 540M |
| Digital | 4.5 | 27 | 34m | 4.75 | 5.25 |
LT6600-5 | 5M |
| Resistor | 0 |
| 28m | 2.7 | 11 |
AD8137 | 76M | 450 | Resistor |
|
| 3.2m | 2.7 | 12 |
AD8139 | 410M | 800 | Resistor |
|
| 24.5m | 4.5 | 12 |
LT5514 | 850M |
| Digital | 10.5 | 33 | 64m | 4.75 | 5.25 |
AD8370 | 750M | 5.75k | Digital | -11 | 34 | 79m | 3 | 5.5 |
AD8351 | 2.2G | 13k | Analog | 0 | 26 | 28m | 3 | 5.5 |
LT6600-2.5 | 2.5M |
| Resistor | 0 |
| 26m | 2.7 | 11 |
AD8369 | 600M | 1.2k | Digital | -10 | 40 | 37m | 3 | 5.5 |
LT6600-10 | 10M |
| Resistor | 0 |
| 39m | 2.7 | 11 |
LT6600-20 | 20M |
| Resistor | 0 |
| 46m | 2.7 | 11 |
LTC1992 | 3.2M | 1.5 | Resistor | 0 |
| 650μ | 2.7 | 12 |
LTC1992-1 | 3M | 1.5 | Fixed | 0 | 0 | 650μ | 2.7 | 12 |
LTC1992-10 | 4M | 2 | Fixed | 20 | 20 | 650μ | 2.7 | 12 |
LTC1992-2 | 4M | 2 | Fixed | 6 | 6 | 650μ | 2.7 | 12 |
LTC1992-5 | 4M | 2 | Fixed | 14 | 14 | 650μ | 2.7 | 12 |
LT1567 | 5M | 55 | Analog |
|
| 11m | 2.7 | 12 |
AD8132 | 350M | 1.2k | Resistor |
|
| 12m | 2.7 | 11 |
AD8131 | 400M | 2k | Fixed | 6 | 6 | 11.5m | 2.8 | 11 |
AD8138 | 320M | 1.15k | Resistor |
|
| 20m | 3 | 11 |
AD8138S | 320M | 1.15k | Resistor |
|
| 20m | 3 | 11 |
AD8350 | 900M | 2k | Analog, Fixed | 20 | 20 | 30m | 5 | 10 |
